Mars Lander Team Prepares for "Seven Minutes of Terror"
National Geographic News ^ | 5-13-2008 | Lander Team Prepares for "Seven Minutes of Terror"<b>Victoria Jaggard

Posted on 05/13/2008 8:24:55 PM PDT by blam

Mars Lander Team Prepares for "Seven Minutes of Terror"

Victoria Jaggard
National Geographic News
May 13, 2008

After years of planning followed by a ten-month journey, the Mars Phoenix Lander is slated to touch down on the red planet's north pole on May 25.

If successful, the probe will be the first lander to reach a Martian pole and the first to actually touch the planet's water ice.

What's more, it could settle the debate over whether Mars was once a habitable world.

Now, as Phoenix closes in on the last 12 million miles (19 million kilometers) of its journey, NASA scientists are gearing up for the "seven minutes of terror" that could make or break the $420-million mission.

"Approximately 14 minutes before touchdown, the vehicle separates from its cruise stage," Barry Goldstein, Phoenix project manager at the Jet Propulsion Laboratory in California, said today at a press conference.

"At this point we lose communication from the vehicle."

Once the craft reaches Mars's atmosphere, the next critical seven minutes make up what's known as the Entry, Descent, and Landing (EDL) phase.

Screaming down at about 12,600 miles (20,270 kilometers) an hour, the craft must open a parachute to slow itself for a three-minute glide to the surface about 70 miles (113 kilometers) below.

The craft's landing sequence then includes steps such as jettisoning its heat shield, extending its legs, and firing its landing thrusters.

"There are 14 pyrotechnic events, and each of those have to work perfectly for this to go as planned," Goldstein said. "Getting EDL communication [at touchdown]—that'll be the three seconds that I am really biting my nails over."

Risen From the Ashes

The tension for this mission seems especially intense, since Phoenix is not the first craft to attempt a landing at a Martian pole. In 1999 NASA lost communication with the Mars Polar Lander as it entered the atmosphere above the planet's south pole.

That lander's fate remains a mystery, but its hardware designs will be given a second chance—Phoenix is based on much of the lost craft's systems.

"We spent 15 years developing the hardware, and I really wanted some return from those," said Peter Smith, Phoenix principal investigator at the University of Arizona in Tucson, who first proposed "recycling" technology from the failed 1999 mission.

Engineers have put the so-called heritage hardware through a battery of tests, and NASA scientists say they have fixed all the known issues.

Teams using a variety of data also put serious thought into where exactly to set the lander down.

"Finding a place to land that was scientifically interesting and safe … has been a multiyear process," noted Ray Arvidson, chair of the Phoenix landing site working group at Washington University in St. Louis, Missouri.

The site, informally dubbed Green Valley, sits in a region of permafrost on Mars's northern plains that is analogous to northern Canada, JPL's Smith said.

The relatively shallow valley, which contains some of the highest concentrations of ice outside of the polar cap, is about 700 feet (213 meters) deep and stretches for 40 miles (64 kilometers).

A crater near the valley means that an impact pushed away most large rocks and spread out a soft cushion of fine particles 5 to 10 inches (13 to 25 centimeters) deep on top of the hard icy soil.

But "this is no trip to grandma's for the weekend," warned Ed Weiler, NASA's associate administrator for the Science Mission Directorate.

"Mars has been known to cause trouble, and I'll be worried until I hear the signal a few seconds after landing."

Search for Life

Still, NASA team members said that the scientific payoffs of a polar mission will be well worth the risks.

As opposed to the Mars rovers that have been exploring the red planet's geologic history, Phoenix will be taking samples that should reveal active processes.

Mars's northern ice cap expands and contracts with the seasons, which should allow scientists to analyze how water impacts the planet's soil chemistry.

And "we'll look at the properties of ice frozen into the surface with water vapor in the atmosphere to see if there's a communication there," Smith said.

But the biggest goal will be to look for signatures that Mars might once have been habitable. (Get full coverage of the search for water—and life—on Mars.)

"We're really doing a full geological and chemical experiment on the surface with the idea of finding if this is a habitable zone," Smith added.

The polar region offers the best hope, he said, because just like the refrigerator in a kitchen, polar ice may "preserve organic material and the history of life on this planet."

The consequence, however, is that the craft is not expected to last beyond the stated lifetime of the mission.

Unlike the Mars rovers that have roamed Mars's equatorial zone since 2004, Phoenix is touching down in a region that within months will be too cold and dark for the craft to maintain power supplies.

"Living in Hawaii would be wonderful, but we live north of the Arctic Circle," JPL's Goldstein said.

"In January [at the start of Martian winter] we'll go three to four months without any solar energy. At that point it's extraordinarily unlikely the craft will survive."


TOPICS: News/Current Events
KEYWORDS: lander; mars; pl; team; terror

1 posted on 05/13/2008 8:24:56 PM PDT by blam
[ Post Reply | Private Reply | View Replies]

To: blam

2 posted on 05/13/2008 8:26:00 PM PDT by blam (Secure the border and enforce the law)
[ Post Reply | Private Reply | To 1 | View Replies]

To: blam
"NASA scientists are gearing up for the "seven minutes of terror" that could make or break the $420-million mission...and each of those have to work perfectly for this to go as planned," Goldstein said."

There are a lot of "if"s going into this mission. Many things can go wrong and $420 mil is a pretty chunk of change.

Well, gotta do what we gotta do. Famous words rekindled for this modern age..."One small, insanely expensive mars probe; One giant leap for mankind"

3 posted on 05/13/2008 8:35:39 PM PDT by BloodOrFreedom
[ Post Reply | Private Reply | To 1 | View Replies]

To: blam
It won't actually land on the pole... it'll be at about 68 degrees north latitude, per this NASA email I got today.

alt
alt
alt
NASA - National Aeronautics and Space Administration Science@NASA Web Site

alt alt Follow this link to skip to the main content
+ NASA Home
+ Search NASA Web
+ Pagina en Español
+ Contact NASA

alt alt
Search Site via Google
alt


alt alt
HOME SATELLITE TRACKING ABOUT MAILING LISTS STORY ARCHIVES OTHER LANGUAGES
alt
alt
alt
alt
FEATURE alt
alt
alt
Phoenix set to land on Mars 05.13.2008



+ Play Audio | + Download Audio | + Email to a friend | + Join mailing list

May 13, 2008: NASA's Phoenix Mars Lander is preparing to end its long journey and begin a three-month mission to taste and sniff fistfuls of Martian soil and buried ice. The lander is scheduled to touch down on the Red Planet on Sunday, May 25th.

see captionPhoenix will enter the top of the Martian atmosphere at almost 13,000 mph. In seven minutes, the spacecraft must complete a challenging sequence of events to slow to about 5 mph before its three legs reach the ground. Confirmation of the landing could come as early as 7:53 p.m. EDT.

Right: An artist's concept of NASA's Phoenix Mars Lander a moment before its 2008 touchdown on the arctic plains of Mars. Pulsed rocket engines control the spacecraft's speed during the final seconds of descent. [Larger image]

"This is not a trip to grandma's house. Putting a spacecraft safely on Mars is hard and risky," said Ed Weiler, associate administrator for NASA's Science Mission Directorate at NASA Headquarters in Washington. "Internationally, fewer than half of all attempts to land on Mars have succeeded."

Rocks large enough to spoil the landing or prevent opening of the solar panels present the greatest known risk. However, images from the High Resolution Imaging Science Experiment (HiRISE) camera on NASA's Mars Reconnaissance Orbiter, detailed enough to show individual rocks smaller than the lander, have helped lessen that risk.

"We have blanketed nearly the entire landing area with HiRISE images," said Ray Arvidson of Washington University in St. Louis, chairman of the Phoenix landing-site working group. "This is one of the least rocky areas on all of Mars and we are confident that rocks will not detrimentally impact the ability of Phoenix to land safely."

see caption

Above: The landing site chosen for NASA's Mars Phoenix Lander, at about 68 degrees north latitude, is much farther north than the sites where previous spacecraft have landed on Mars. [more]

Earlier in 2002, NASA's Mars Odyssey orbiter discovered that plentiful water ice lies just beneath the surface throughout much of high-latitude Mars. NASA chose the Phoenix proposal over 24 other proposals to become the first endeavor in the Mars Scout program of competitively selected missions.

"Phoenix will land farther north on Mars than any previous mission," said Phoenix Project Manager Barry Goldstein of NASA's Jet Propulsion Laboratory, Pasadena, Calif.

The solar-powered robotic lander will manipulate a 7.7-foot arm to scoop up samples of soil and underground ice. Onboard laboratory instruments will analyze the samples. Cameras and a Canadian-supplied weather station will supply other information about the site's environment.

see captionRight: An artist's concept: Months after landing, Phoenix begins to shut down operations as winter sets in. Far-northern latitudes on Mars experience no sunlight during winter, depriving the solar-powered lander of electricity. Frost covering the region as the atmosphere cools will eventually bury Phoenix in ice.

"The Phoenix mission not only studies the northern permafrost region, but also takes the next step in Mars exploration by determining whether this frosty region, which may encompass as much as 25 percent of the Martian surface, is habitable," said Peter Smith, Phoenix principal investigator at the University of Arizona, Tucson.

One research goal is to assess whether conditions at the site ever have been favorable for microbial life. The composition and texture of soil above the ice could give clues to whether the ice ever melts in response to long-term climate cycles. Another important question is whether the scooped-up samples contain carbon-based chemicals that are potential building blocks and food for life itself.

Stay tuned to Science@NASA for updates. And good luck, Phoenix!

SEND THIS STORY TO A FRIEND

Editor: Dr. Tony Phillips | Credit: Science@NASA

more information
Phoenix --mission home page

Credits: The Phoenix mission is led by Smith with project management at JPL. The development partnership is with Lockheed Martin, Denver. International contributions are from the Canadian Space Agency; the University of Neuchatel, Switzerland; the universities of Copenhagen and Aarhus, Denmark; the Max Planck Institute, Germany; and the Finnish Meteorological Institute.

NASA's Future: The Vision for Space Exploration

alt



alt alt

alt
NASA
Curator: Bryan Walls
NASA Official: John M. Horack
Last Updated: June 9, 2005
+ Contact NASA
alt
alt
alt

4 posted on 05/13/2008 8:36:23 PM PDT by MarineBrat (My wife and I took an AIDS vaccination that the Church offers.)
[ Post Reply | Private Reply | To 1 | View Replies]

To: blam

Anyone taking odds on convenient Mission failure?


5 posted on 05/13/2008 9:00:15 PM PDT by Crim (Dont frak with the Zeitgeist....)
[ Post Reply | Private Reply | To 1 | View Replies]

To: Crim
Is your post intended to be positive or negative?
6 posted on 05/13/2008 10:23:03 PM PDT by Buffalo Head (Illigitimi non carborundum)
[ Post Reply | Private Reply | To 5 | View Replies]

To: blam; potlatch; devolve; MeekOneGOP
Fascinating and necessary. I would like very much for them to succeed and I know that if they don't they will keep trying because they must.

This exploration is an imperative apart from the polital-humanitarian follies played out by fools.

7 posted on 05/13/2008 10:35:46 PM PDT by PhilDragoo (Hitlery: das Butch von Buchenvald)
[ Post Reply | Private Reply | To 1 | View Replies]

To: blam

Why use a stationary Lander when the other two worked so well?


8 posted on 05/13/2008 10:43:07 PM PDT by Steve Van Doorn (*in my best Eric cartman voice* 'I love you guys')
[ Post Reply | Private Reply | To 1 | View Replies]

To: PhilDragoo; potlatch

.

This time they won’t mix up metric and standard parameters I hope!

I thought I had some good Martian graphics - I’ll heve to dig through my toys


9 posted on 05/13/2008 10:43:42 PM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 7 | View Replies]

To: Buffalo Head

“Is your post intended to be positive or negative?”

Neutral....there are other states of being than just + or -


10 posted on 05/13/2008 10:44:46 PM PDT by Crim (Dont frak with the Zeitgeist....)
[ Post Reply | Private Reply | To 6 | View Replies]

To: PhilDragoo; potlatch; ntnychik; MeekOneGOP


11 posted on 05/13/2008 11:37:51 PM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 7 | View Replies]

To: potlatch; PhilDragoo

12 posted on 05/14/2008 12:17:00 AM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 11 | View Replies]

To: blam
There are 14 pyrotechnic events, and each of those have to work perfectly for this to go as planned

Amazing how Rube Goldbergy these things HAVE to be. Fourteen pyrotechnic events after sitting in a deep freezer for six months... gee... I don't know if my truck would start after sitting in the garage for six months. And that's only one pyrotechnic event, and not one stored in a deep freezer either.

Definitely going to be a nerve-wracking landing, that's for sure. Got my fingers crossed. Go Phoenix!

13 posted on 05/14/2008 12:44:34 AM PDT by LibWhacker
[ Post Reply | Private Reply | To 1 | View Replies]

To: blam

May 25. I’m glad I saw this and will look forward to the landing. Hope they play it up in the news so I don’t miss it.


14 posted on 05/14/2008 1:12:17 AM PDT by BlueVelvet
[ Post Reply | Private Reply | To 2 | View Replies]

To: Crim

Don’t say that, we want it to succeed. Think good thoughts.


15 posted on 05/14/2008 1:12:18 AM PDT by BlueVelvet
[ Post Reply | Private Reply | To 5 | View Replies]

To: devolve

Your pictures are so pretty. I don’t know how you can do that, make them move like that.


16 posted on 05/14/2008 1:12:18 AM PDT by BlueVelvet
[ Post Reply | Private Reply | To 12 | View Replies]

To: blam

bump


17 posted on 05/14/2008 1:13:51 AM PDT by Captain Beyond (The Hammer of the gods! (Just a cool line from a Led Zep song))
[ Post Reply | Private Reply | To 1 | View Replies]

To: devolve

Nice graphics way to go.


18 posted on 05/14/2008 1:15:04 AM PDT by Captain Beyond (The Hammer of the gods! (Just a cool line from a Led Zep song))
[ Post Reply | Private Reply | To 11 | View Replies]

To: BlueVelvet; potlatch

.

The first one - X-Files + Mars is 3 layers of animated .gifs

The second one is one composite animated image - this Star Trek graphic is an animated Star Trek scene I made last year and just added the blue UAV (current unmanned aircraft) and the small swirling space oddity just to the right of it

I don’t use a computer to create these - I use a WebTV Plus


19 posted on 05/14/2008 2:44:17 AM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 16 | View Replies]

To: devolve

Three layers of animated gifs, I have no idea how you would do that. Is it really hard to learn?. The blue UAV thing really moves and the stars are cool.

I wish I could do that.


20 posted on 05/14/2008 3:41:15 AM PDT by BlueVelvet
[ Post Reply | Private Reply | To 19 | View Replies]

To: devolve

Bet Phil liked this, very flashy.


21 posted on 05/14/2008 3:46:39 AM PDT by potlatch
[ Post Reply | Private Reply | To 11 | View Replies]

To: devolve

Very nice posting


22 posted on 05/14/2008 3:47:31 AM PDT by potlatch
[ Post Reply | Private Reply | To 12 | View Replies]

To: Captain Beyond; potlatch


Thanks - We're always looking for space related and NASA and JPL threads

I use a lot of JPL and NASA photographs and add animated backgrounds and NASA / Hubbell photographed objects we animate

It's a shame we cannot add embedded autoloading background music to these - I can add Flash audio (.swf with embedded .wavs or .mp3s ) - but only WebTV and MSN-TV browsers will detect and play it







23 posted on 05/14/2008 3:47:42 AM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 18 | View Replies]

To: devolve

Bumparoo


24 posted on 05/14/2008 3:48:02 AM PDT by potlatch
[ Post Reply | Private Reply | To 19 | View Replies]

To: blam

I wonder is Sheila Jackson Lee will want to see the flag the astronauts put there.


25 posted on 05/14/2008 3:49:42 AM PDT by mathluv
[ Post Reply | Private Reply | To 1 | View Replies]

To: potlatch

.

LOL!

Piper gotcha up?


26 posted on 05/14/2008 3:54:58 AM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 24 | View Replies]

To: devolve

I haven’t been to sleep yet

signing off


27 posted on 05/14/2008 3:56:55 AM PDT by potlatch
[ Post Reply | Private Reply | To 26 | View Replies]

To: potlatch

Piper must be hungry!


28 posted on 05/14/2008 4:13:46 AM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 24 | View Replies]

To: devolve; potlatch

click!


29 posted on 05/14/2008 8:51:18 AM PDT by PhilDragoo (Hitlery: das Butch von Buchenvald)
[ Post Reply | Private Reply | To 9 | View Replies]

To: devolve
Lol, roiling around inside the cube! Pretty post devolve, thanks for posting it to me.
30 posted on 05/14/2008 4:51:52 PM PDT by potlatch
[ Post Reply | Private Reply | To 28 | View Replies]

To: devolve

Very nice. New one I believe.


31 posted on 05/14/2008 4:53:11 PM PDT by potlatch
[ Post Reply | Private Reply | To 23 | View Replies]

To: potlatch

.

Yes - new

Just 2 .gifs there

The BG is a large 980x735 animation


32 posted on 05/14/2008 5:11:22 PM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 31 | View Replies]

To: devolve

New one, that’s nice. Even has the space rock in it. You went to a lot of trouble. The little ‘swarmy’ thing, lol.


33 posted on 05/14/2008 5:16:14 PM PDT by potlatch
[ Post Reply | Private Reply | To 32 | View Replies]

To: potlatch

.

I get these ideas in the middle of the night!

If I don’t finish it then - It never comes out as I visualized -


34 posted on 05/14/2008 5:41:12 PM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 33 | View Replies]

To: devolve

I think of things at bedtime and jot them down, with directions, lol.


35 posted on 05/14/2008 5:49:26 PM PDT by potlatch
[ Post Reply | Private Reply | To 34 | View Replies]

To: BlueVelvet

Welcome to FR !


36 posted on 05/14/2008 5:50:33 PM PDT by tomkat (helping keep American craftsmanship alive)
[ Post Reply | Private Reply | To 16 | View Replies]

To: potlatch

.

LOL!

I use to use a mini-recorder!


37 posted on 05/14/2008 6:10:57 PM PDT by devolve ( -- -The_Project_Islamic_Hope_website_banner no_longer_features_Barack_Hussein_Obama_Junior)
[ Post Reply | Private Reply | To 35 | View Replies]

To: devolve

[I use to use a mini-recorder!]

Nothing funny about that, it’s an excellent idea.
Just noted a new poster. Wonder how many Freepers there are now?


38 posted on 05/14/2008 6:18:52 PM PDT by potlatch
[ Post Reply | Private Reply | To 37 | View Replies]

To: tomkat

Thank you, you are the first to say that!


39 posted on 05/14/2008 6:45:44 PM PDT by BlueVelvet
[ Post Reply | Private Reply | To 36 | View Replies]

To: BlueVelvet
Thank you, you are the first to say that!

You're welcome, tho I find it rather surprising, as I'm one of the slower ones in the class . .

40 posted on 05/14/2008 6:55:09 PM PDT by tomkat (helping keep American craftsmanship alive)
[ Post Reply | Private Reply | To 39 | View Replies]

To: devolve

Wow, thanks for wasting crappy hotel bandwidth with humongous and nonsensical graphics.


41 posted on 05/14/2008 7:02:24 PM PDT by Doohickey (SSN-681; SSN-671; SSN-669; SSN-712)
[ Post Reply | Private Reply | To 12 | View Replies]

To: tomkat

You were the A student this time.


42 posted on 05/14/2008 7:03:16 PM PDT by BlueVelvet
[ Post Reply | Private Reply | To 40 | View Replies]

To: potlatch
Wonder how many Freepers there are now?

China is coming online. Could be a few million soon.

43 posted on 05/14/2008 7:06:12 PM PDT by don-o (Free Lazamataz!)
[ Post Reply | Private Reply | To 38 | View Replies]

To: don-o; devolve

[China is coming online. Could be a few million soon.]

Oh please! Maybe a limit should be set on the forum, lol. It still runs slow for me and I’m on cable!


44 posted on 05/14/2008 7:08:26 PM PDT by potlatch
[ Post Reply | Private Reply | To 43 | View Replies]

To: blam

45 posted on 05/21/2008 3:13:50 PM PDT by cartoonistx
[ Post Reply | Private Reply | To 2 | View Replies]

Disclaimer: Opinions posted on Free Republic are those of the individual posters and do not necessarily represent the opinion of Free Republic or its management. All materials posted herein are protected by copyright law and the exemption for fair use of copyrighted works.

Free Republic
Browse · Search
News/Activism
Topics · Post Article

FreeRepublic, LLC, PO BOX 9771, FRESNO, CA 93794
FreeRepublic.com is powered by software copyright 2000-2008 John Robinson
